Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig

1 комплект/комплекты
MOQ
negotiable
цена
Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Название продукта: буровая установка для водяных скважин
Имя: установленная тележкой буровая установка водяной скважины
Тип мощности: Дизель
мощность (Вт): 70KW /90KW /132KW
Глубина бурения: 300 м
Диаметр сверления: 260mm, 350mm, 505mm
Роторный вращающий момент: 9500-15500N.m
Скорость вращения: 0-90 Rpm
Грязный насос: BW450/30 BW600/30 BW850/30
Приложение: буровая установка буровой установки водяной скважины мобильная, сверля хорошо
особенность: Высокая сверля эффективность, гидравлический контролировать, многофункциональный
Диаметр шпинделя сверлильного станка: 102/108/114mm
Длина сверла: 2.0m 3.0m 6.0m
Тип: Роторная буровая установка
Гарантия: 1 год
Использование: Хорошо воды
Размер(л*ш*ч): 11500*2500*4150MM
Масса: 29000 KG
Выделить:

hydraulic well drilling machine

,

truck mounted drilling rig

,

industrial water supply rig

Основная информация
Место происхождения: Чжэцзян, Китай
Фирменное наименование: SANROCK
Сертификация: IOS9001 CCC
Номер модели: SRTM300
Оплата и доставка Условия
Упаковывая детали: Обнаженная упаковка для машин, деревянная коробка для запасных частей или потребительский спрос.
Время доставки: 30 дней
Условия оплаты: LC,D/A,D/P,T/T,Western Union,MoneyGram
Поставка способности: 1000 комплектов/наборов в месяц
Характер продукции

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 0

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 1

Truck-mounted water well drilling rigs are prized for their mobility and efficiency, making them essential in a variety of scenarios where accessible and reliable water sources are needed.

Emergency and Disaster Relief Following natural disasters like earthquakes, floods, or droughts, truck-mounted rigs are rapidly deployed to drill emergency water wells to provide a temporary but vital supply of fresh water for affected populations when existing infrastructure is destroyed or contaminated. emergency water well, disaster relief drilling rig

Construction and Industrial Water Supply These rigs are used on construction sites to provide water for dust control, compaction, and mixing concrete. They are also used for dewatering purposes and to supply water to mining camps, factories, or other industrial facilities located away from city water lines.construction site water well, dewatering wells, industrial water supply drilling.

Geotechnical Surveying and Environmental Monitoring Before major construction projects, these rigs are used to drill boreholes for soil sampling and geological surveys. They are also used to install monitoring wells to track groundwater quality and levels for environmental assessments.monitoring well installation, geotechnical drilling services.

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 2

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 3

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 4

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 5

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 6


Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 7

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 8


Products Description

SANROCK TRUCK-MOUNTED DRILLING RIG SRTM300C COMPREHENSIVE OVERVIEW
DEPTH
300-400M
300-400M
300-400M
DRILLING DIAMETER
260MM
350MM
505MM
DIMENSIONS
9500*2500*3350MM
10500*2500*3600MM
11500*2500*4150MM
TOTAL WEIGHT
22000KG
25000KG
29000KG
TRUCK CHASSIS
POWER
400HP
400HP
400HP
DRIVING FORM
6*4
6*4
6*4
DRILLING TOWER,SECOND FLOOR CHASSIS
DRILLING TOWER
RETRACTABLE
RETRACTABLE
FIXED PIPE RACK TYPE
DRILL TOWER LOAD
28T
45T
50T
DRILL TOWER HEIGHT
6M
8M
8M
PULL DOWN
10T
15T
15T
PULL UP
20T
25T
30T
DRILLING RIG POWER
DIESEL ENGINE
OPTIONAL
Customization
Customization
RATED POWER
70KW
90KW
132KW
TOOL HOIST
MODEL
ZYJ2B
SINGLE ROPE PULL UP
2T
HYDRAULIC POWER HEAD
TORQUE
9500NM
11500NM
15500NM
REVOLUTIONS
0-70RPM
0-90RPM
0-90RPM
OTHER PARTS AND COMPONENTS
FOAM PUMP
B-36EX1
FLOW
42L/MIN
PRESSURE
4MPA
REVOLUTIONS
660R/MIN
MUD PUMP
BW450/30
BW600/30
BW850/30
FLOW
450L/MIN
600L/MIN
850L/MIN
PRESSURE
3MPA

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 9

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 10

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 11

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 12

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 13

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 14

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 15

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 16

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 17

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 18


Company Profile

Quzhou Sanrock Heavy Industry Machinery Co.,Ltd is founded in 2017, fastly develop as a key enterprise in the industry of mine field, geological exploration, water well field and engineering construction field, with the ability to research, manufacture and market.
Sanrock products now cover more than 10 species such as:
Mining Drilling Rig                           Engineering Drilling Rig
Underground Drilling Rig                          Solar Pile Drilling Rig
Water Well Drilling Rig                            Rotary Drilling Rig
Core Drilling Rig                        Air Compressor
We have many year experience in these fields to offer various solutions, with ISO 9001 and CE certificate to guarantee our quality control.  We also have excellent engineer and sale teams to serve different customers' demand.
We also offer comprehensive after-sales service support, including on-site installation guidance, operation training and regular maintenance services, to ensure that customers have no worries during the use of the equipment.
We Sanrock here wish to hand in hand with our customers,create better future!
This is just a part of the overseas clients who came to our company to negotiate cooperation, sign contracts and take photos.
We welcome more overseas clients to come to our company for negotiation and cooperation.

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 19

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 20

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 21

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 22

Hydraulic Well Drilling Machine Construction And Industrial Water Supply High Efficiency Water Well Drilling Rig 23

Do you provide design drawing and customization services for complete machines and drilling tools?
Please provide your technical specifications or project background details, and we are ready to develop a customized proposal based on your requirements.
This includes 2D and 3D design drawings , delivered in various formats including DWG, PDF, STEP, and IGES.
Our engineering team specializes in developing tailored solutions that meet your specific operational requirements, geological conditions, and performance objectives.


How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping.
Shipping efficiency depends on country and city you want to ship to.
For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


How is your quality control?
We have our own experienced QC.  There will be strict inspection and testing for every order before shipping out.
Our comprehensive inspection service goes beyond basic checks. We analyze performance,and provide a detailed report to maximize your uptime, reduce operating costs, and extend the lifespan of your equipment.
