Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

1 комплект/комплектов
MOQ
negotiable
цена
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Наименование продукта: Скрутный компрессор, компрессорная машина.
Название: Дизельный компрессор воздуха винта
Сила: 410 кВт
Источник питания: Дизельное топливо
Давление: 21-25bar/21-34bar
Потребление воздуха: 31-29 м2/мин 36,5-32 м2/мин
СТРЕД: 1600/1400 оборотов в минуту 1830/1400 оборотов в минуту
Вместимость топливного бака: 700 л
Емкость смазывая масла: 120 л
Способ охлаждения: И воздух/водяное охлаждение доступное
Применение: Горный проект, уголь, руда
Тип: Пошёл на хуй.
Основные компоненты: ПЛК, сосуд высокого давления, двигатель, двигатель, насос, подшипник
Конфигурация: Недвижимость
Размер ((l*w*h): 4100*1800*2050 мм
Вес: 5600kg
Выделить:

Diesel Screw Air Compressor

,

Rotary Screw Air Compressor

,

Rotary Screw Drive Air Compressor

Основная информация
Место происхождения: Чжэцзян, Китай
Фирменное наименование: SANROCK
Сертификация: CE ISO 9001:2015
Номер модели: Настраиваемый
Оплата и доставка Условия
Упаковывая детали: Обнаженный пакет для машин, деревянная коробка для запасных частей, или по требованию клиента.
Время доставки: 18-25 рабочих дней
Условия оплаты: Аккредитив, Документы против акцепта, Документы против платежа, Банковский перевод, Western Union, M
Поставка способности: 5000 комплектов в месяц
Характер продукции

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 0Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 1

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 2

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 3



Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 4Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 5

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 6Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 7

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 8

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 9

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 10Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 11Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 12
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 13Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 14





Company Profile

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 15

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 16

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 17

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
