Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor

1 комплект/комплектов
MOQ
negotiable
цена
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Наименование продукта: Скрутный компрессор, компрессорная машина.
Название: Дизельный компрессор воздуха винта
Сила: 410 кВт
Источник питания: Дизельное топливо
Давление: 21-25bar/21-34bar
Потребление воздуха: 31-29 м2/мин 36,5-32 м2/мин
СТРЕД: 1600/1400 оборотов в минуту 1830/1400 оборотов в минуту
Вместимость топливного бака: 700 л
Емкость смазывая масла: 120 л
Способ охлаждения: И воздух/водяное охлаждение доступное
Применение: Горный проект, уголь, руда
Тип: Пошёл на хуй.
Основные компоненты: ПЛК, сосуд высокого давления, двигатель, двигатель, насос, подшипник
Конфигурация: Недвижимость
Размер ((l*w*h): 4100*1800*2050 мм
Вес: 5600kg
Выделить:

Mining Screw Air Compressor 34bar

,

Mobile Screw Air Compressor

,

Screw Air Compressor Machine 25bar

Основная информация
Место происхождения: Чжэцзян, Китай
Фирменное наименование: SANROCK
Сертификация: CE ISO 9001:2015
Номер модели: Настраиваемый
Оплата и доставка Условия
Упаковывая детали: Обнаженный пакет для машин, деревянная коробка для запасных частей, или по требованию клиента.
Время доставки: 18-25 рабочих дней
Условия оплаты: Аккредитив, Документы против акцепта, Документы против платежа, Банковский перевод, Western Union, M
Поставка способности: 5000 комплектов в месяц
Характер продукции

Stationary Screw Air Compressor
A stationary screw air compressor is a robust, high-efficiency industrial air compression system designed for continuous operation in demanding environments. Utilizing dual rotary screw rotors, it delivers smooth, pulsation-free compressed air with energy efficiency and low maintenance requirements. The fixed installation ensures stability and noise reduction. Equipped with smart control systems, automatic drainage, and low-maintenance design, these compressors provide reliable performance in diverse environments.

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 0Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 1



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 2

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 3

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 4Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 5



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 6

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 8

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 10

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 11

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 12Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 13

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 14Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 15

Company Profile

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 16

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 17

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 18

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
